Description
MK5 DOUBLE ACTING PUMPS
Whale’s Tough and Lightweight Polypropylene Range
Tough proven, reliable designs available with single or double acting capabilities.
MK5 DOUBLE ACTING Manual Bilge Pump. High output – 104 litres/23 US gals/minute. Twin diaphragms – empty 2 bilge compartments at the same time or one twice as quickly – 2 manifolds supplied.
Features and Benefits
Mk5 Double Acting high performance
¥ Ease of maintenance inspection hatch – no tools required
¥ Will continue to pump even if one diaphragm fails
Tip: It is important to ensure that a vented anti-syphon loop is incorporated in the system. Accreditations & Approvals
¥ Suitable as a primary bilge pump on boats equal to or greater than 12m (40ft) in accordance with ISO15083
¥ Life Boats Approval – approved by Lloyds (MCA) and USCG (Mk5 Universal MCA Size 2) (Mk5 Double Acting – Size 3)
Performance data:
Suction Lift: 1m (3ft)
Discharge Head: 0.5m (1.5ft)
45 Strokes per Minute: 64 litres (17 US gals)
70 Strokes per Minute: 104 litres (27.5 US gals)
Specifications:
Weight – 3.04
Product Type – Pumps > Manual Pumps > Bilge Pumps
