Description
The Jabsco Xylem HotShot HD5 12V DC is a high-flow, high-pressure diaphragm washdown pump. This heavy duty (HD) model features a wide diameter motor (compared to standard non-HD models) with a powder-coated shell, cast aluminium endbells and lower housing to improve pressure capability and life.
The pump has vibration-dampening feet for quiet operation and an integrated, sealed pressure switch for on-demand operation. It has a dry self-priming capability of 2.1 meters (7ft) and can run dry without damage.
The Jabsco Xylem HotShot HD5 is supplied with quick connect straight hose barb and GHT fittings, a 90° 20 mesh quick connect strainer and trigger nozzle and quick connect hose adapters.
– Voltage: 12V DC
– Open flow GPM (LPM): 5 (19)
– Shut-off pressure PSI (BAR): 70 (4.8)
– Max. current AMPS: 16.0
– Recommended fuse size: 25A
– Dimensions: 9.6″ in length, 5.0″ in width, 4.7″ in height / 244(L) x 127(W) x 119(H)mm
Weight – 3.265
SKU – JAB-P501J-119N
Product Type – Pumps > Washdown Pumps > Washdown Pumps
