Description
Blue Sea M-Series battery selector switch 6008 with 3 positions in red. The battery switch isolates battery banks to all loads or combines battery banks to all loads.
Switch Type: Selector
Colour: Red
Switch Positions: 3
Battery Combine: No
Alternator Field Disconnect: No
Maximum Voltage: 32V DC
Stud Size: 3/8″
Terminal Stud Torque: 120 in-lb (13.56 Nm)
Continuous Rating: 300A
Intermittent Rating: 500A (5 Min)
Cranking Rating 30 sec: 900A
Battery Inputs: 2
Cable Clearance For 4/0 AWG Cables: 28.45mm (1.12″)
Mounting Holes: Accept #10 Screw
Stud Material: Tinned Copper
Stud Torque: 120 in-lb (13.56 Nm)
Terminal Stud Size: 3/8″ – 16 (M10)
Weight: 0.35 kg (0.77lb)
Approvals: CE, IP66, ISO 8846, UL 1107 & UL 1500
Weight – 0.354
Product Type – Electrical & Navigation > Batteries & Accessories > Battery Switches
